LOCATION
It is important to find a good location for your pool so that you can get the most out of its benefits. It is therefore recommended to consider the following tips.
- Choose the place most exposed to the sun in the morning.
- Put the pool in a place protected from the wind so as not to lose heat/water.
- Think about your privacy.
- Avoid installing it near trees / shrubs, source of trouble: the fall of leaves, pollen or flowers, as well as the presence of insects and birds.
- Provide that the water supply and electricity are nearby.
- As far as possible, plan to place the skimmer facing the prevailing wind (or slightly obliquely), lengthwise; this will improve water surface cleaning as well as filtration. New paragraph
PREPARATION DU TERRAIN
The location of the pool must be absolutely flat and level.
If this is not the case you will have to flatten it so as not to compromise the stability of the pool.
During the installation work, use a "spirit level" to check the leveling as well as at the end of the assembly to check that the swimming pool has been assembled correctly. In any case, remove the thickness of grass and turf.
The preparation of the ground must be done on firm ground and not on a recent embankment or brought back ground, even seeming packed. If the land is sloping, soil must be removed from the upper part and not added to the lower part.
When the ground is well leveled, cleared of any stones, grass or roots. The pool struts must always be placed on a solid surface of approximately 45x45 cm. To delineate the perimeter corresponding to the size of the pool, use flour or chalk, this will allow you to better visualize the area to be prepared.
In correspondence of each leg, remove approximately 2/3 cm from the surface of the ground already prepared, to put reinforced concrete slabs or otherwise large planks resistant to the weight of the swimming pool full of water.
In this way you have a safer and more aesthetic installation. You can optionally add a thin layer of sand (3/4 cm) to level the surface. If you have to put your pool on a cement or stone floor, make sure it is not gritty; we advise you to put protection between the pool and the ground, such as a rot-proof and anti-cryptogamic groundsheet. It is best to carry out these assembly operations in good weather without wind, with a temperature between 15°/25°. It is preferable that you are 2/3 people for these operations.
IMPORTANT CONSIDERATIONS / TIPS
- It is advisable to put under the swimming pool a soft, rot-proof mat whichwill protect the pool and increase your comfort: ask ourresellers for purchase.
- Never forget that a full swimming pool has a very important weight. For thisreason only install it on a surface with sufficient strength.
- If the ground is particularly soft, we advise you to put undereach foot of the pool a 30x30 cm concrete garden "slab"thickness 4 cm, so that the pool does not sink. It is also possible tolevel these slabs by wedging them with a mixture of sand and cementdried up.
- Important: never drag the pool on the ground, it can be damaged!
POOL COMPOSITION
Your swimming pool is made up of different elements which vary according to the model.Before starting the assembly, sort all the elements and classify themby category at your fingertips. All swimming pools are composed of:
- A plastic-coated fabric pocket (indicated by the letter A)
- 130 cm tubes (B) for all models
- 110 cm tubes (B1) only for EASY 943 and 635 marked with asticker
- 60 cm tubes (C)
- Angular tubes (D)
- Basic corner spacers (E)
- Basic straight spacers 130 cm (F)
- Basic straight spacers 110 cm (F 1) only EASY 943 and 635 markedof a sticker
- From legs to trestle (G)
- A pvc pouch containing assembly instructions, gloves andspare springs (small and large model).
No. : Our swimming pools do not need screws or bolts to bemounted!
POOL ASSEMBLY
Unlike other pools, simply similar in appearance to ourmodels, the EASY series pockets, are fully supported by ametal structure that supports the mass of water and its weight. For this reason heis essential that the structure is perfectly assembled, that the spacers, theangular tubes and all other parts are positioned and insertedperfectly, as indicated in the instructions, this in order not to compromiseneither the proper functioning nor the aesthetics of your swimming pool. After preparing theground, set up the rot-proof mat, traced the perimeter of the swimming pool andprepared the parts, assemble as shown below.
- Lay out and unfold pocket A on the prepared ground.
- Make sure that the location of the skimmer is placed facing the windsdominant or slightly oblique, this will save you from having to dismantle everything againand will ensure a well-cleaned pool on the surface.
- Position the trestle legs G in front of the corresponding slots which areare on the top edge of the pocket.
- To give stability to the structure, the feet with support leg G will have tobe assembled on the ground, to each other, using straight spacers F andin the 4 corners by the corner spacers E, so as to obtain aperfect and firm perimeter.
- Before closing the perimeter in the corners, remember to insert the 4tie rods (welded to the base of the corners of the pocket) in the corner spacersbasic E.
- Insert the 130 cm B and 60 cm C tubes into each other (bring out thelocking pawls) so as to form the planned length of tubes infollowing the diagram below, which differs according to the models.
Pool Long side Short side
EASY 942 B B C B C
EASY 941 B1 B1 B1 C B C
EASY 632 B B B C B C
EASY 635 B B B B B C B1 B1 C
EASY 943 B B B B B B C B1 B1 C
- Completely thread the tubes obtained along the edges of the pocket,starting from the existing openings in the 4 corners of the pocket; either for thelong side than for the short side of the pool, the terminal tubes mostcourts, indicated by the letter C, must be opposite diagonally.
- It is also important that the holes of all the metal tubes arepositioned exactly in correspondence of the cut-outs, are visible andturned downwards.
- Then insert in each of the holes of the tubes, the feet with strut, qui will naturally correspond to the number of planned cuts and whichconstitute the supporting structure of the swimming pool.
- Once this operation has been carried out, your pool is almost ready. There remainsonly to complete the upper perimeter by putting the 4 angular tubes Das follows: thread one of the two ends of theangled tube and push it under the length of tubes (do notnest it for now). Fit the other end of the angled tubein the end of the other length of tube; pull slightly outwardand fit the other end previously threaded under the tube.
- Stretch the bottom of the pool and remove the creases by simultaneously pulling thepocket at the base of the opposite ends, using as a handle thetie rods welded to the base of the corners of the pocket.
- Mount the skimmer kit as shown below.
- Check that the strut feet are perfectly aligned;begin to fill the pool with water, gradually eliminating anycreases that would persist.
- Fill the pool with water up to 10 cm from the edge, no more.
POOL DISASSEMBLY
To disassemble your pool, simply do the opposite of what you didduring assembly but also follow our advice. Do not lift the pool when there isstill water in it. To empty the pool more easily, use theplugs located at the bottom of the pocket, siphons, cellar pumpsor the filter pump. Wash all the parts with liquid soap and wash them well.wipe dry before storing. Never use talcum powder and put the pouch in aflexible and robust bag, well separated from the metal parts in order to avoidhitches. Store the pool in a dry place, not too exposed to cold,heat and rodents.
IMPORTANT TIPS
- It is not recommended to leave children unsupervised near the swimming pool.
- Do not dive and do not sit on the edge of the pool.
- Keep the instructions for future consultations.
- Use the sterilization equipment or chemicals offered by yourtrusted dealer; the quantities depend on the dimension of yourswimming pool and its use and environment.
- Do not throw solid treatment products directly into the pool(risk of staining). Use the skimmer or a floating chlorine dispenser.
- For perfect use of your swimming pool, scrupulously follow theinstructions and advice and if you have any problems, contact yourdealer.
- We also advise you, for this type of pool, to use accessoriesstandards supplied by us, such as skimmers, filters, ladders,covers and all products for cleaning and maintaining your swimming pool.
CUSTOMER SUPPORT CENTER
Our customer support center will always be at your disposal for youassist with assembly, for the choice of accessories or any repairsdue to accidental damage.
