THE WINKY 4 POOL: A DEPTH OF 1.10

It is the smallest of the round PVC pools in the Zodiac Original range, and comes from the Zodiac Original design offices, after years of experience and success with the famous Zodiac boat. The principle of the Zodiac Original swimming pools is simple, the Zodiac technology of the boat adapted to the above-ground swimming pool with a patented principle of pressurizing the PVC structure by water, simple and effective...


The Winky 4 pool is installed on flat ground, without a concrete slab, which must first be covered with one to two centimeters of sand in order to smooth out any roughness and with a layer of rot-proof felt, totally essential to protect the surface. Zodiac Original pool from the constant humidity of the ground.

Zodiac Original Winky pools can be installed as an above-ground pool or a semi-buried pool from 60 to 70cm depending. These pools can be set up every year but also withstand winters very well, provided they are fitted with the Zodiac winter cover. This cover will save you having to dismantle and reassemble in the fall and spring.

The assembly of a Zodiac Original pool is simple, accessible to all, two or three people depending on the model, it is the filling time which represents the longest moment but whatever happens you can swim during the day even, at worst, the next day!

The Zodiac Original Winky kit, apart from promotions during fair periods, is made up of the swimming pool accessories essential for its use, the pump, the sand filter, the skimmer, the Zodiac Original ladder, the electric inflator as well as the plumbing, except for the rot-proof felt to be placed before assembly.

COMPOSITION OF THE ZODIAC ORIGINAL STANDARD POOL KIT

- A basin (basin belt belt fixing accessories protective cover set of plugs comfort halyard 1/4 turn valve (for discharge));
- SF 1106 AMS sand filtration (system flow 7.1m³/h);
- Sand for filtration;
- A floating skimmer;
- A L120/6 ZP stainless steel safety ladder (to be adapted on site for semi-buried pools);
- An electric pump;
- A Ø 38mm pipe kit;
- Assembly instructions.

COMPLEMENTARY ACCESSORIES

- the Zodiac Original bubble cover with roller;
- the Zodiac Original winter cover;
- the programmable electrical box;
- the spot ;
- the Zodiac robot;
- the automatic pH regulator.

TECHNICAL CHARACTERISTICS

- overall: Ø 5.00 height 1.20m;
- body of water: Ø 3.80 m;
- volume of water: 13 m³.

Manufactured under Zodiac© Original technology license | Packaging: 1 pallet 80 x 120cm
